Manufacturing System

LOADER The process of automatically supplying the PCB loaded on the magazine to the post-process through the pusher

SCREEN PRINTER The process of printing Solder Cream on a single-sided or double-sided PCB pad

SPI The process of inspecting the volume of the printed Solder Paste

MOUNT The process of mounting various types of SMDs on the PCB pad surface printed with Solder Cream

AOI The process of inspecting the appearance state (defective contact, defective soldering, etc.) of the PCB

ICT The process of inspecting the characteristics of the circuit and component elements of the PCB

UNLOADER The process of automatically loading the transmitted PBA into Magazine

COATING The process of applying a protective coating solution to the PBA on which the parts are mounted

ROUTER The process of separating the PBA in the Array state

PRESS The process of notching and bending the heatsink parts in the array state

STAKING The process of compressing and fixing the assembled MODULE with heat and pressure

VISION INSPECTION A process of determining a defective product by checking the amount of light and electrical SPEC output after applying a voltage (current) to the assembled product

VISUAL INSPECTION The process of visually inspecting the completed MODULE product
